Product introduction
| Type | Fixed Hydraulic Dock Ramp |
| Model | DCQ10-0.7 |
| Loading Capacity | 10000 kgs |
Fixed hydraulic dock ramp is an auxiliary equipment for forklift/truck/van to load and
unload goods quickly.
The forklift/truck/van can drive into carriage directly from ground
to load and unload the goods.
It is helpful to reduce labor work and multiple increase the work
efficiency.
Product parameters
| Model | Capacity load (kg) | Platform Size(mm) | Lip (mm) | Travel(mm) | Power (kw) | Pit size(mm) |
| Upper | Lower | L | W | H |
| DCQ6-0.55 | 6000 | 2000*2000 | 400 | 300 | 250 | 0.75 | 2060 | 2040 | 600 |
| DCQ6-0.7 | 6000 | 2500*2000 | 400 | 400 | 300 | 0.75 | 2560 | 2040 | 600 |
| DCQ8-0.55 | 8000 | 2000*2000 | 400 | 300 | 250 | 0.75 | 2060 | 2040 | 600 |
| DCQ8-0.7 | 8000 | 2500*2000 | 400 | 400 | 300 | 0.75 | 2560 | 2040 | 600 |
| DCQ10-0.55 | 10000 | 2000*2000 | 400 | 300 | 250 | 0.75 | 2060 | 2040 | 600 |
| DCQ10-0.7 | 10000 | 2500*2000 | 400 | 400 | 300 | 0.75 | 2560 | 2040 | 600 |
Product display
Product characteristics
The stationary yard ramp is operated easily with electricity and
hydraulic power. It is classified to five kinds by carrying-weight
capacity, such as 6T, 8T, 10T, 12T, 15T etc.
2. Stationary yard ramp also can according to different models and
the loading process of the change in the car, automatically adjust
the height.
3. Introduction of foreign advanced technology manufacturing
hydraulic system, reliable.
4. This product according to the different needs of the users, in
terms of dimensions does special design to withstand loads.
