Electric Forklift Battery Charger 30A One Year Warranty CE ISO9001
Certification
| Type | Forklift Battery Charger |
| Model | CZB5C 48V/30A |
| Application | Electric Forklift |
| Battery parameter | 48V 175-240Ah
|
Introduction:
CZC7 series automatic charger is an advanced Hi-Tech product with
strong functions and smart shape. It is featured with small size,
light weight, easy operated, high charging efficiency and high
reliability ; It combines the high frequency technology with
micro-processor controlling technology in one unit to reach the
best charging result for the battery, effectively to prolong the
battery set’s working cycle life, all the charging process is
automatically executed according to the program without the
operator on duty.
Application:
Ideal charging equipment for electric pallet truck, electric
mover, electric lift, electric tour car and various of electric
power driven vehicles.
Installation for the charger
1. Conditions for installation
The charger must be placed in a dry room with good ventilation. To
keep all the venting holes on the charger clean for avoiding over
heat. There is no corrosive and acidic gas near to the charger to
avoid corrosion for the charger.
The charger should place on the ground for operation.
2. Connection to the power supply
To connect to the power supply according to the requirements
stipulated in the nameplate or operating instruction
Single-phase AC220V three cables (one for L, one for N; one for PE)
To connect the input cables of charger to L, N and PE of the power
supply according to the marks. The connection to the power supply
must be done by the electrical engineer according to the local
standards. Otherwise, the case of the charger must be grounded.
3. Connection to the battery
Connecting the positive “+” and negative “-”of the battery with the
positive “+” and negative “-”of the charger’s output respectively.
Product Catalogs:
Type, data item | CZC7- 50A/24V | CZC7- 30A/36V | CZC7- 25A/48V | CZC7- 30A/48V | CZC7- 30A/72V | |
| Input Volt. V,Hz | 1Ph. 220-240V 50～60Hz |
| Input current A | 10 | 9 | 10 | 12 | 17 | |
| Charge.Current A | 50 | 30 | 25 | 30 | 30 | |
| Output Power kW | 1.8 | 1.62 | 1.8 | 2.16 | 3.24 | |
Charge.Range V Ah | 24 290-400 | 36 174-240 | 48 145-200 | 48 174-240 | 72 174-240 | |
| Size mm | 220×405×140 | 300×430 ×180 | |
| Net weight kg | 8.3 | 11 | |
Product Features:
- Electric quantity controlling, timing controlling to ensure battery
complete charging, auto-shut down after charging complete, no
over-charging, no under-charging;
- High brightness LEDs indicating charger’s running state;
- Adopting IWUIa multi-stage charging style ( this charging style is
applied for the general lead-acid battery charging);
- Adopting IWUUa multi-stage charging style ( this charging style is
applied for the free maintenance lead-acid battery charging);
- Nixie tubes indicating battery voltage, charging current, capacity,
time etc.;
- With auto-checking, time-delay start, soft-start functions;
- With the temperature compensation function for constant voltage
point, floating charging point(CZC 7A adjustable charger is without
this feature);
- With keeping charging function;
- Balanced charging to ensure the consistency of battery cell
capacity;
- Automatic initial charging function;(Only the general lead-acid
battery charging)
- With the protection of open circuit, over load, short circuit and
over temperature ;
- With the function of information enquiring, to enquire past 20
times charging record;
- Memory during power interruption and self starting again;
- CZC7A adjustable charger can set charging voltage/current, multiple
application for various specifications of battery.
