CZB5C 65A 48V Forklift Battery Charger Automatic Silicon-Controlled Rectifier

Model: CZB5C 48V/65A

Phase: Three Phases

Introduction:

CZB5C Series Intelligent Charger is the organic combination of leakage transformer, technology of Silicon-controlled rectifier and Microcomputer Control. This device could optimize Wsa+Pulse charging characteristic curve. As charge voltage of battery increases, charge current decreases automatically.

Pulse charge would be performed before gas emissions or in late stage of recharge. On the premise of guarantee adequate battery power, this device would lower greatly internal temperature

and reduce gas emissions of battery, prolong the life of battery effectively and raise the charging

efficiency eventually.

The whole product has simple structure, convenient operation, complete functions and high efficiency.

Application:

This device would be applicable to recharge of lead-acid batteries which could be used in

various electric vehicle such as power pallet trucks, fork-lift truck, lift truck, electronic tour bus.

Product Catalogs:

1. Three-phase AC(3/PE) input power voltage.

Product Features:

• The Voltage and current double closed-loop framework is applied in the PID control technology. This device can achieve dynamic tracking and automatic adjustment of charge parameters.
• Nixie tube would display charger parameters such as battery voltage, charge current, capacity and recharged time. It could als show the code of charging curve and fault. High-intensity LED lamp would indicate running state of this charging unit.
• Functions of automatic detection, delaying and soft-start, Function of temperature compensation. The voltage of tipping point of gas emission would change with the temperature.
• Tis device could also record data as the end of recharge for 30 times.
• Protection and alarm functions of open crcuit, reverse connection, over load and short circuit breakdown.
• Protection and alarm functions of overheat fault of transformer and module.
• Equalization charge could ensure caacity consistency of battery packs, function of automatic initial charge, function of desulfuration charge.

Our Cutomers

LAKER AUTO PARTS CO., LIMITED is ONE-STOP-SHOP offering parts and accessories for forklifts trucks, low-speed electric vehicles, and auxiliary material handling equipment​ with a guaranteed high-performance product at the most competitive price.

Our core products are as follows,

• Lead acid Batteries for Electric forklift trucks and Electric vehicles,
• Intelligent automatic battery chargers including industrial frequency and high frequency,
• Regular black and non-marking solid tires for forklifts used at small working fields and warehouses,
• Hydraulic solid tire press machine for mounting and dismounting the solid tires,
• Mobile loading ramp and fixed dock leveler for loading the container and goods,
• Low-speed Electric vehicle with loading platform 1Ton to 3Ton for warehouse/airport/port dock material delivery.
• and various of battery accessories for application of maintenance and replacement. ​(Such as battery plates, gauntlets, connectors, battery watering systems, battery safety valves, battery vent plugs, battery cables and etc.)

At LAKER, we are dedicated to providing comprehensive, quality service from the initial quotation to final product delivery.

Our commitment to service, knowledge, and product availability has made us a One-Stop-Shop for our customers and their business needs.

All the Forklift relevant products are selected from top-class manufacturers under their own brand MYING and LAKER, supported by skilled technicians on standby for any technical query online or solution after-market.

LAKER sincerely hopes to be your best choice for the power solution and maintenance of the Forklift!
