SCR 60A Diode Rectifier Fork Truck Battery Charger , Lorry Battery Charger

Model: 48V/60A

Phase: Three Phases

Introduction:

◆ This charger adopt the up-to-date SCM and serveal decades of charging experience to develop the SCR series of automatic intelligent charger,it is widely used for the flooded traction battery.

◆ It can carry out the normal charge and equalising charge automatically. It is suitable for single shift or multi shifts.

◆ Charge time between 8 and 12 hours

◆ It has a simple structure, reliable performance and lower operating and maintenance cost.Simple to operate.

Application:

This device would be applicable to recharge of lead-acid batteries which could be used in

various electric vehicle such as power pallet trucks, fork-lift truck, lift truck, electronic tour bus.

Product Catalogs:

Product Features:

◆ The charge process can be controlled intelligently with a microprocesser. optimized charge performance to get a excellent charge results.

◆ Wa+Equalising charge curves.

◆ The temperature rising during the charge and the evaporating of the electrolyte at the end of charge can be restricted through the controlling the charge specifications,this can prolong the battery life and reduce the lost volume of water, so it can reduce the maintenance cost.

◆ Intelligent, fully automatic.

◆ The advance technology and excellent units guarantee the reliable quality and perfomance.

◆ Self-diagnosis and display panel indicating operational conditions.

◆ It can be selected to carry out normal charge or one equqlising charge after normal charge through the adjustment of the switch.

◆ It can judge the polanrity reverse and open-circuit automatically then alarm.

High power factor and low power aberrance.

◆ The voltage of the power source can be 220V,230V and 240V or 380V, 400V and 420V,10% deviation of the total power source voltage is allowed.

◆ Supply frequency 50Hz, 60Hz.

Operation and safety

◆ It can be started and stopped by one key. Once it is started, it can charge automatically to the end without caring.

◆ It can display the charge information by pressing the information key.

◆ It has a switch for Wa or Wa+Eq to select the normal charge or normal with equalizing charge

◆ Detailed charge monitoring display

◆ Optimized design and compact structure. The main units are all specially produced with excellent safety.

◆ The charger can test the polarity and open-circuit automatically before charge and then alarm.

◆ Restrict the over-current and over-voltage and then alarm.

◆ The charger can be started and stopped at any time by pressing on/off key.

◆ The charger will inspect the temperature in the charger during run-time.

◆ It is controlled by micro-computer and it can judge a plenty of the abnomal conditions during charge to protect from overcharge.

◆ Electromagnetic compatibility and electrical safely conform to EC standards.

The soft cable it used has excellent flexibility and insulation.

Warnings

1. The charger must be selected according to the battery type and capacity (ampere hour). The wrong matching will make the battery to release more gas, boiling even explosion. Do not charge the battery, which is in parallel connection or the battery, which is not allowable to be charged.
2. The specialist must check the matching between the battery and charger, it is must be guaranteed that the connection from the battery to the charger is always correct.
3. Please read the operating instructions before using, the precautions and operating conditions must be abided.
4. To keep all the venting holes clean to avoid over-heating. Keeping away from liquid or short circuit will happen.
5. There is high voltage in the charger, and it is very dangerous, so it is allowable to open and maintain the charger by the specialists.
6. It is forbidden to adjust and change the charger inside for safety.
