28x9-15 8.25-15 Forklift Tire Press Machine 120Ton ISO9001
Certification
| Type | Solid Tire Press Machine |
| Model | TP120 |
| Application | Mounting and dismounting solid tires |
| Capacity | 120Ton |
| Work hydraulic | 15Mpa |
| Range of applicable tire rim | 8inch to 15inch |
Introduction
Professional equipment for amending or replacing solid tires or OTR
tires.
1.2MN solid tyre pressing machine is a special equipment for solid
tire loading and unloading,
It can also apply to the tyres below 15 ".
This machine is a frame type structure.The hydraulic cylinder is
located above the piston movement from top to bottom, the
department. Platform, fixed on the piston rod and spherical
pressure box, firm structure, is made of high-quality materials
carefully assembled, so good performance. With the electric control
box independent.
The hydraulic system of the machine consists of hydraulic system
and hydraulic system of the auxiliary machine. This machine
hydraulic system is composed of the high-pressure pump, solenoid
valve, pressure relief valve, check valve, pressure indicator and
oil cylinder.
High pressure relief valve is the oil pressure setting of high
pressure pump, its maximum setting value is 12MPa.
Product Specification
- Heavy duty frame: The construction is welded by large-scale beam
and channel beam.
- High-grade Hydraulic Cylinder: The biston rod is grinded and
hard-chromium plated.
- Easy pull and press into the rims.
- Voltage and phase customized according to different power supply.
| Model | TP120 |
Nominal pressure | 1.2 MN |
Work hydraulic | 15 Mpa |
| Max Tire Size | 15 Inches |
| Max Cylinder Stroke | 600 mm |
| Motor | 4 KW |
| Oil Tank Capacity | 90 L |
| Size | L2050xW650xH2200 mm |
| Weight | 1600 kg |
Usage method of forklift tire press
First of all , choose a good tooling correctly, put the mould on
the work table, and then put the wheel on the mould, handling
pressure head to Press the die on the tire and finally with the
boot ring loaded. Different types of tyres and wheels need
different tooling, the user to install the tire before the
selection of tooling, then the disassembly and assembly operations,
it will be very convenient and quick. According to the motion mode
and the size of the machine, the machine can be divided into manual
press and electric press, which is generally suitable for large
tonnage forklift truck or truck tire.
